Bosch LBB 4442 / 00 line monitoring device lbb4442 / 00-cn f.01u.097.257



▶ No additional wiring is required for speaker line monitoring

▶ The power amplifier has built-in main monitoring equipment
▶ Auxiliary monitoring equipment is installed at the end of loudspeaker line
▶ Open circuit fault detection
▶ Compatible with 100 V and 70 V speaker lines
▶ The power amplifier supplies power to the auxiliary monitoring equipment
The Praesideo system uses a unique loudspeaker line monitoring principle without the need to install additional cables. The loudspeaker line itself can be used to communicate with the auxiliary monitoring equipment installed at the end of the loudspeaker line. The LBB 4442 / 00 contains the main and auxiliary equipment for monitoring a single speaker line. If you want to monitor multiple speaker line branches and speakers, it is recommended to use the lbb4440 / 00 monitoring control board with LBB 4441 / 00 and LBB 4443 / 00 monitoring boards.
basic function
Each amplifier channel in the LBB 442x / x0 power amplifier unit provides internal mechanical and electrical support for the lbb4442 / 00 main monitoring board. The auxiliary monitoring board is suitable for Bosch series loudspeakers and can be installed in the last speaker on the line or in a separate housing at the end of the line. The power amplifier has built-in short-circuit grounding and short-circuit detection functions. The system can detect and report line faults within 100 seconds. The pilot tone generator used to monitor the loudspeaker is generated in the amplifier, which enhances the function of the auxiliary monitoring equipment. Users can turn off and turn on the line monitoring function through the configuration software.
Interconnect components
· 20 pin flat cable connector (main)
Two screw terminals (auxiliary)
Certificate and recognition
Regional certification
European CE declaration of conformity
Traction
TUEVSUED
TUV
GL GL
Immunity en 55103-2
Radiation en 55103-1 / fcc-47 part 15B
Installation / configuration
The following loudspeakers can be installed with a monitoring board:

High directional loudspeaker with sound column of ceiling loudspeaker
LC1‑WM06E LBC 3210/00 LBC 3432/01
LC1‑UM06E LA1‑UM20E LS1‑OC100E
LC1‑UM12E LA1‑UM40E
Lc1-um24e horn speaker
High directional loudspeaker with sound column of ceiling loudspeaker
LBC 3510/40 LBC 3403/16
LBC 3520/40 LBC 3404/16
LBC 3530/40 LBC 3405/16
Speaker LBC 3406 / 16
LBC 3011/41 LH1‑10M10E
LBC 3011/51 LBC 3482/00
LB1‑UM06E LBC 3483/00
LBC 3018/00 LBC 3484/00
technical specifications
Mechanical index
auxiliary equipment
Dimensions (H x W x D) 16 x 80 x 60 mm (0.6 x 3.1 x 2.3 in)
Weight 50 g (1.7 oz)
Install 2 screws
Main equipment
Dimensions (H x W x D) 17 x 60 x 50 mm (0.7 x 2.3 x 2 in)
Weight 30 g (1.1 oz)
Installed inside Praesideo power amplifier
Environmental requirements
Operating temperature - 5 ° C to + 55 ° C (+ 23 to 131 ° f)
Storage temperature - 20 ° C to + 70 ° C (- 4 to 158 ° f)
Humidity 15% to 90%
Air pressure 600 to 1100 HPA
Ordering Information
The LBB 4442 / 00 line monitoring device contains a master card and a slave card for monitoring a single speaker line.
LBB4442/00
Hardware accessories
The LBB 4446 / 00 monitoring board bracket Kit (10 per set) is used to install the LBB 4442 / 00 auxiliary monitoring board. LBB 4446/00
