summary



Programmable Wall Station (PWS) is a modular wall mounted control system. Typical applications include volume control, source selection, preset selection and room combination.



The pws-4 and pws-6 interface units are installed in the standard electrical post box. A pws-c energy coupler needs pws-4 and pws-6 modules. Pws-c is connected to the blue code N8000 and n8000-1500 system controllers on the CAN bus. The pws-c parallel connector allows simple daisy chains of multiple units at different locations.
The pws-4 / pws-6 module provides a simple, blue code system with programmable control and DSP parameters. The buttons can be configured for one time, block, or broadcast group, and all status LEDs display the current status.
pws-4
The pws-4 panel provides four programmable buttons that can be configured freely through such functions as source selection, mute, preset parameters, recall, iris net, and a variety of other functions. The pws-4 also provides two up / down buttons that can be used for variable parameters such as level or gain control.
pws-6
The pws-6 panel provides six programmable buttons that can be configured freely via iris net such as source, parameter selection, mute, preset, recall, and a variety of other functions.
pws-c
Yes, the backplane interface between pws-c pws-4 / pws-6 panels, and blue code system controller, can bus, and external power supply. It is characterized by a simple daisy chain of multiple different positions of PWS CS parallel connection. Each pws-c can support any combination of up to three pws-4 / pws-6 panels in a single location through the attached ribbon cable. Pws-pws-pws-pws-pws-pws-pws-pws
Additional features:
Up to three pws-4 / pws-6 units at wallstation
Simple daisy chain up to three 4 / 6 module PWS for arbitrary combination use including connecting cable and pws-c. single location
Easy button label
Label field protected by transparent cover. A tag generation utility, including with iris net.
Configuration via iris network
Buttons and lights are available for a variety of functions and are fully configurable and customizable.
Specifications
Bus interface: 10 pole terminal
Power consumption: 480 MW (pws-c), 175 MW, 150 MW (pws-4) (pws-6)
Supply voltage: 9 58 V DC
Power supply current: 20 mA @ 24 V DC (pws-c)
Network control (iris network): Yes
