summary



The programmable Wall Station (PWS) is the modular wall mounted control of the blue code system. Typical applications include volume control, source selection, preset selection and room combination.
The pws-4 and pws-6 interface units are installed in the standard electrical post box. A pws-c energy coupler needs pws-4 and pws-6 modules. Pws-c is connected to the blue code N8000 and n8000-1500 system controllers on the CAN bus. The pws-c parallel connector allows simple daisy chains of multiple units at different locations.
The pws-4 / pws-6 module provides a simple, blue code system with programmable control and DSP parameters. The buttons can be configured for one time, block, or broadcast group, and all status LEDs display the current status.
pws-4
The pws-4 panel provides four programmable buttons that can be configured freely through such functions as source selection, mute, preset parameters, recall, iris net, and a variety of other functions. The pws-4 also provides two up / down buttons that can be used for variable parameters such as level or gain control.
pws-6
The pws-6 panel provides six programmable buttons that can be configured freely via iris net such as source, parameter selection, mute, preset, recall, and a variety of other functions.
pws-c
Yes, the backplane interface between pws-c pws-4 / pws-6 panels, and blue code system controller, can bus, and external power supply. It is characterized by a simple daisy chain of multiple different positions of PWS CS parallel connection. Each pws-c can support any combination of up to three pws-4 / pws-6 panels in a single location through the attached ribbon cable. Pws-pws-pws-pws-pws-pws-pws-pws
Additional features:
Up to three pws-4 / pws-6 units at wallstation
Simple daisy chain up to three 4 / 6 module PWS for arbitrary combination use including connecting cable and pws-c. single location
Easy button label
Label field protected by transparent cover. A tag generation utility, including with iris net.
Configuration via iris network
Buttons and LEDs are fully configurable and customizable for a variety of functions.
Function module standard installation, keyboard volume, blue code, convenient control source, preset, etc. up to three front units can be connected in wallstation pws-c. the front unit can be daisy chained, and the bus can be easily connected with simple marks including connecting lines, integrated status indicator buttons and led configuration through transparent cover, and behavior protection (instantaneous, locking, or broadcasting) of customized buttons through iris network
Specification: 10 pole can bus interface terminal network control (iris network): Yes, power consumption: 480 MW (pws-c), 175 MW, 150 MW (pws-4) (pws-6) power current: 20 mA @ 24 V DC (pws-c) power supply voltage: 9-58 V
