Bosch provides a full range of volume controllers and sound

 source selectors to achieve a sound public address solution. Basic function operation public address system is usually used for information and background music transmission. The volume controller can be used to adjust the volume level locally. In addition to the fader, a sound source selector can be installed to allow local selection of five different sources. When a (emergency) broadcast is required, the built-in relay ensures that the message is broadcast at a preset volume level, regardless of the local volume setting. Depending on the rated power, the fader is available in three models: 12 W, 36 W and 100 W. The total load of the speakers connected to the fader must not exceed the rated power. In addition, the three models are available in the following two versions. One is the power-saving 4-wire volume coverage Version (/ 10 models), which activates the coverage relay in the event of an emergency call. The other is the fail safe 4-wire volume override Version (/ 20 model), which deactivates the override relay in the event of an emergency call. The design and color of the fader can be perfectly integrated into any indoor occasion. In addition, in the design process, the installation simplicity, operation convenience and reliability are optimized. Interconnect assembly screw connection certificate and approved safety en 60065 flame retardant UL 94 V0 installation / configuration LBC 1400 / 10 and LBC 1400 / 20 dimensions in mm LBC 1410 / 10 and LBC 1410 / 20 dimensions in mm LBC 1420 / 10 and LBC 1420 / 20 dimensions in mm LBC 1430 / 10 size in mm lm1-smb-mk Dimensions (in mm) lm1-smb-mk detail LBC 1400 / 10 circuit diagram 2 | LBC 14x0 / x0 MK volume controller and LBC 1430 / 10 source selector LBC 1400 / 20 circuit diagram LBC 1410 / 20 circuit diagram LBC 1420 / 10 circuit diagram LBC 1430 / 10 circuit diagram technical specification LBC 1400 / 10 and / 20 rated power 12 W input voltage 100 V Attenuation 5 x 3 dB + turn off frequency response 50 Hz to 20 kHz (- 1 dB) thd < 0.5% 3 | LBC 14x0 / x0 MK volume controller and LBC 1430 / 10 sound source selector current consumption 20 mA, 24 VDC LBC 1410 / 10 and / 20 rated power 36 w input voltage 100 V attenuation amplitude 8 x 3 dB + turn off frequency response 50 Hz to 20 kHz (- 1 dB) thd < 0.5% current consumption 20 mA, 24 VDC LBC 1420 / 10 And / 20 rated power 100 W input voltage 100 V attenuation amplitude 10 x 2 dB + turn off frequency response 50 Hz to 20 kHz (- 1 dB) thd < 0.5% current consumption 20 mA, 24 VDC LBC 1430 / 10 rated power 100 W input voltage 100 V sound source number 5 sound sources + turn off mechanical index LBC 1400 / 10 and / 20 size (W x H x T) 87 x 87 x 45.6 mm weight 226 g color white (RAL 9010) LBC 1410 / 10 and / 20 dimensions (W x H x D) 87 x 87 x 45.6 mm weight 227 g color white (RAL 9010) LBC 1420 / 10 and / 20 size (W x H x D) 87 x 147 x 61.5 mm weight 512 g (including surface mounting box) color white (RAL 9010) LBC 1430 / 10 inch (W x H x D) 87 x 87 x 32.9 mm weight 125 g color White (RAL 9010) lm1-smb-mk dimensions (W x H x D) 87.3 x 87.3 x 50 mm weight 73 g color white (RAL 9010) environmental requirements operating temperature - 10 ° C to + 55 ° C (+ 14 ° f to + 131 ° f) storage temperature - 40 ° C to + 70 ° C (- 40 ° to + 158 ° f) relative humidity < 95% order information LBC 1400 / 10 volume control, 12 W, MK mounting type, built-in 24 VDC coverage relay, energy saving version, 5 attenuation steps (3 dB increase each time) and off, white ral 9010. Order No. lbc1400 / 10 LBC 1400 / 20 volume controller volume control, 12 W, MK mounting type, built-in 24 VDC coverage relay, fail safe version, 5 attenuation steps (3 dB increments each time) and off, white ral 9010. Order No. lbc1400 / 20 LBC 1410 / 10 volume controller volume control, 36 W, MK mounting type, built-in 24 VDC coverage relay, energy saving version, 8 attenuation steps (3 dB increase each time) and off, white ral 9010. Order No. lbc1410 / 10 LBC 1410 / 20 volume controller volume control, 36 W, MK mounting type, built-in 24 VDC coverage relay, fail safe version, 8 attenuation steps (3 dB increments each time) and off, white ral 9010. Order No. lbc1410 / 20 LBC 1420 / 10 volume controller volume control, 100 W, MKD / E2 mounting type, built-in 24 VDC coverage relay, energy-saving version, 10 attenuation steps (2 dB increase each time) and off, white ral 9010, surface mount box is provided. Order No. lbc1420 / 10 LBC 1420 / 20 volume controller volume control, 100 W, MKD / E2 mounting type, built-in 24 VDC coverage relay, fail safe version, 10 attenuation steps (2 dB increments each time) and off, white ral 9010, with surface mount box provided. Order number lbc1420 / 20 LBC 1430 / 10 source selector, MK mounting type, 5 channel selection, white ral 9010. Order No. lbc1430 / 10 hardware accessory LM1 ￣ SMB ￣ MK surface mounting box for volume control lbc1400 / 10, lbc1400 / 20, lbc1410 / 10, lbc1410 / 20 and sound source selector lbc1430 / 10, white ral 9010. Order No. lm1-smb-mk

Sales telephone (same number of wechat): 13428785305 QQ: 2461903042
