Huawei Huawei vcn540-64 8-bit 64 channel network hard disk recorder video storage cloud node

Product features

High performance and flexible application

Support 64 channel network video access, 320mbps video input bandwidth

Support single machine application mode, multi machine stack application mode, and cascade with vcn3000 series

High reliability of application mode

Support the design of hard disk shockproof technology and reduce the failure rate of hard disk

Support dual system design, effectively reduce business interruption and video loss risk

Support cloud cluster function, equipment failure, and service balance switch to other devices

Support safevideo+ function, storage data on demand redundancy

Support cache supplementary recording technology to ensure the integrity of video data

Embedded Linux operating system, support 7 × Stable operation for 24 hours and not easy

Intelligent analysis of hackers and viruses

Support Huawei intelligent camera, perimeter intrusion, trip detection, hover detection, object

Access and linkage of multiple intelligent analysis functions for legacy and object removal

Easy to deploy, maintain and free system disk design, and the equipment can be used when it is started

Support hot plug and play of hard disk, and automatically discover configuration

Support status indication, device and hard disk status are clear at a glance

Technical parameters product model vcn540-64 equipment performance

Network video input 64 channel network video input bandwidth 320mbps

128 routes of forwarding playback and 32 channels of download

Network video output bandwidth 320mbps

Local video decoding video formats H.264, h265

Decoding performance 2-way HDMI, supporting 1-way 4K (3840 * 2160), or 4-way 1080p, or

8-way 720p, or 16-way D1 and below resolution decoding

Preview mode 1 / 4 / 8 / 9 / 16 screen

Platform performance stack characteristics 2-16 stack networks

Client stand alone and heap scenario: 32 login users

Stand alone: local man-machine supports 1 user storage capacity, 8 disks

Disk interface sata3.0, hot plug support, built-in-3.5 "handle bar

Hard disk type enterprise hard disk: 4tb, 6tb, 8tb

RAID level raid0, RAID1, RAID5

Video management video mode supports manual recording, planned video and multi alarm linkage triggered video

Video protection supports safevideo+, and redundancy protection is performed for data according to channel or time

Query by time and event

Download in batch and in sections

Security features media security features support aes256 and other encryption algorithms

Watermark feature supports front-end digital watermark and generates alarm after tampering

Reliability characteristics dual system feature support

Media transmission supports bandwidth adaptation, multicast, FEC, SEC and other characteristics

Cluster feature n + 0 cluster, 3-8 support cluster networking, dynamic load balancing, fault point migration

The insurance box of mobile business data supports the backup of key data of the system and automatically restores the business data of the system

Compatibility device access supports Huawei front end SDK, gb/t 28181, onvif 2.4 and onvif profile s and other protocols

Platform access supports gb/t 28181, which enables interconnection with other platforms and implements the implementation

Time browsing, video on demand, cloud mirror control, alarm reporting and other services (only as subordinate domain)

Management and maintenance management mode supports b/s and c/s management methods

Log download supports operation log and run log

External interface HDMI interface 1 * HDMI 2.0, 1 * HDMI 1.4 VGA interface 1 * VGA

Network interface 2 * 10 / 100 / 1000m Ethernet port

USB interface 1 USB3.0 and 1 USB2.0 Interface

Audio input 1, BNC interface

Audio output 1, BNC interface

Alarm input 4-way alarm output 2 channels

Other operating temperature 0 ° C～45 ° C

Working humidity 5% - 95% (non condensing)

Power consumption (including disk) ＜ 100W

Power supply 100-240Vac, 50/60hz

Overall dimension mm (width × deep × (high)

Dimensions without lugs (main body size of equipment):

442mm × 420mm × 86.1mm

Size with lug: 484mm × 420mm × 86.1mm

19 inch 2U standard chassis weight (including hard disk) < 14kg (including 8 hard disks)

Certification information type inspection t28181 certification of Ministry of public security of China

Huawei IVS intelligent video monitoring product color page 11

Overseas CE, ROHS, reach, WEEE, FCC, IC, NRTL, CCC,

CQC, certification of nine countries

technical specifications

Style Vcn510 series VCN520-32 VCN540-64

VCN510-8 VCN510-8P VCN510-16 VCN510-16P VCN510-16PD

Video access 8-way, 128mbps 8-way, 128mbps 16 way, 256mbps 16 way, 256mbps 16 way, 256mbps 32-way, 320mbps 64 way, 320mbps

Decoding performance 1 way 4k/8 road 1080p 1 way 4k/8 road 1080p 2-way 4K / 8 road 1080p 2-way 4K / 8 road 1080p 2-way 4K / 8 road 1080p 2-way 4K / 8 road 1080p 2-way 4K / 8 road 1080p

/16 way 720P / 16 way 720P / 16 way 720P / 16 way 720P / 16 way 720P / 16 way 720P / 16 way 720P

Number of hard disks two two two two two four eight

RAID level Metadata: RAID1 video data: RAID1 safevideo+ Metadata: RAID1 video data: RAID1 safevideo+ Metadata: RAID1 video data: RAID1 safevideo+ Metadata: RAID1 video data: RAID1 safevideo+ Metadata: RAID1 video data: RAID1 safevideo+ Metadata: RAID1 video data: RAID5 safevideo+ Metadata: RAID1 video data: RAID5 safevideo+

Network port 2 x 10 / 100 / 1000M 1 x 10/100/1000m 2 x 10 / 100 / 1000M 1 x 10/100/1000m 1 x 10/100/1000m 2 x 10 / 100 / 1000M 2 x 10 / 100 / 1000M

Ethernet port Ethernet port Ethernet port Ethernet port Ethernet port Ethernet port Ethernet port

And 8 10/100m Ethernet ports And 8 10/100m Ethernet ports And 8 10/100m Ethernet ports （ 4*POE+，4*POE++） （ 4*POE+，4*POE++） （ 4*POE+，4*POE++） HDMI, VGA interface 1 hdmi2.0 1 hdmi2.0 1 hdmi2.0 1 hdmi2.0 1 hdmi2.0 1 hdmi2.0 1 hdmi2.0

1 VGA 1 VGA 1 VGA 1 VGA 1 VGA 1 VGA 1 hdmi1.4

1 VGA

Power Supply 100~240VAC 100~240VAC 100~240VAC 100~240VAC - 50~-56VDC 100~240VAC 100~240VAC

50/60HZ 50/60HZ 50/60HZ 50/60HZ Single power supply 50/60HZ 50/60HZ

Single power supply Single power supply Single power supply Single power supply Single power supply Single power supply

Power consumption (including disk) ＜ 60W ＜ 60W ＜ 60W ＜ 60W ＜ 60W ＜ 100W ＜ 150W

(without Poe power supply) （ Without Poe power supply) （ Without Poe power supply)

Dimensions: width x depth x height unit: mm 442*310*43.6 442*310*43.6 442*310*43.6 442*310*43.6 442*310*43.6 442*420*86.1 442*420*86.1

(without hanging ears)
