Z-SHP5331LH

Enhanced super wide dynamic

Full HD IR network hemispherical camera

Z-SHP5331LH

Enhanced super wide dynamic

Full HD IR network hemispherical camera

■ key features

1080p Full HD real-time image up to 60fps*1

· about 1 / 2.8 "high sensitivity MOS sensor.

High sensitivity MOS sensor creates high-definition 1920x1080 super high resolution image.

In 16:9 mode, the sub stream can also be selected 800x600@30fps *June 2015.

? 133dB wide dynamic range shooting can be achieved.

High sensitivity day night conversion function (infrared filter color to black):

When f1.7, it is 0.07lux in color mode; 01 lux in black and white mode.

Internal infrared LED.

The output power of infrared LED lamp can be automatically controlled according to the surrounding environment, so that the camera can be controlled automatically

Can clearly capture face images without overexposure.

RS485 interface, which can communicate with the banknote machine, access control and other RS485 devices.

AC 24V / POE dual power interface.

The super wide dynamic technology of face ensures the clear face image.

VMD (video mobile detection) has 4 zones, 15 sensitivity and 10 detection dimensions.

The privacy area can cover 8 areas, such as windows and entrances and exits.

Camera caption display: the browser can display up to 20 characters.

Alarm source contains three terminal input, VMD and Panasonic alarm instructions.

Full duplex bidirectional audio can support interactive communication between front-end camera and back-end monitoring platform.

? fog leakage compensation function.

· multi languages: Chinese / English / Italian / French / German / Spanish / Portugal

Language / Russian / Japanese.

- conform to onvif.

*1. Super wide dynamic function will be automatically turned off in 60fps mode.

■ appearance

video camera image sensor MOS image sensor type 1/2.8

Effective pixel About 2.35 megapixels

Scan mode progressive scanning

Minimum illumination Color: less than 0.07lux, black and white: 0.01LUX

Color: less than 0.005lux, black and white: 0.0007lux (maximum shutter: 16/30 seconds at f1.7, gain: on (high)) *1

Infrared LED Off / Auto (high / medium / low)

Infrared LED light exposure distance About 30m

white balance AWC(2,000~10,000K)，ATW1(2,700~6,000K)，ATW2(2,000~6,000K)

Light quantity control mode Outdoor: ALC and ELC are automatically combined, indoor (50Hz): ALC and ELC and strobe, indoor (60Hz): ALC and ELC and strobe

shutter speed [ 2 megapixel [16:9] (60fps mode)

Off (1/60), 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000

Super wide dynamic *2 On (high) / on (normal) / off

Super wide face dynamic On / off (only in super wide dynamic: on)

ABS (automatic dark area compensation) On / off (only in super wide dynamic: off)

Fog leakage compensation On / off (only when super wide dynamic / automatic dark area compensation: off)

AGC 1 / 1000 seconds, 1 / 500 seconds, 1 / 250 seconds, 1 / 100 seconds, 1 / 60 seconds, 1 / 30s, 2 / 30s, 4 / 30s, 6 / 30s, 10 / 30s, 16 / 30s Max

Day night conversion (infrared filter color to black) Off / on / Auto 1 (normal) / Auto 2 (infrared light) / automatic 3 (SCC)

dynamic range 133dB (super wide dynamic: on, light control mode: indoor)

Digital noise reduction High / low

Video mobile detection 4 areas, sensitivity: Level 15, detection range: level 10

Privacy zone Up to 8 areas

VIQS Up to 8 areas

Camera subtitle (OSD) Up to 20 characters (letters, symbols)

Focus adjustment AF / manual (HTML only)

camera lens focal length 2.8~9.5mm

visual angle [ 16: 9 mode] level: 31.6 ˚( Far away) ~110.4 ˚( Wide angle)

Vertical: 17.9 ˚( Far away) ~60.2 ˚ ( Wide angle)

[4:3 mode] level: 26.8 ˚( Far away) ~91.0 ˚ ( Wide angle)

Vertical: 19.8 ˚( Far away) ~66.4 ˚ ( Wide angle)

Maximum aperture ratio 1: 1.7 (wide angle) ~1:3.5 (far sighted)

Focus Range 0.3 m~∞

Adjust the angle Level: ± one hundred and eighty ˚， Vertical: 0-85 ˚， Image tilt adjustment range: ˚( Left) ~+100 ˚( Right)

browser

GUI audio frequency Microphone (connector) input: on / off volume adjustment: low / medium / high

GUI audio output: on / off volume adjustment: low / medium / high

SD memory card data download Still or moving images recorded in sdxc/sdhc/sd memory card can be downloaded

GUI / set menu language Chinese / English / Italian / French / German / Spanish / Portuguese / Russian / Japanese

system log Up to 100 records (built-in memory)

network network interface 10Base-T / 100base TX, RJ-45 port

Image resolution Image capture mode

2 megapixel [16:9] (30/60fps) 1,920x1.080 / 1,280x720 / 640x360 / 320x180 / 160x90

*In 30fps mode, the sub stream can also choose 800x600

H.264*3 transmission mode Constant bit rate / frame rate first / best effect / advanced VBR

Frame rate 1 / 3 / 5 / 7.5 / 10 / 12 / 15 / 20 / 30 / 60fps

image quality

Transmission type Low / normal / fine

Unicast / multicast

JPEG image quality Grade 10

Audio compression G.726 (ADPCM) 32kbps / 16kbps，G.711 64kbps / AAC-LC

Audio mode Off / microphone (connector) I / audio out / Interactive (half duplex) / Interactive (full duplex)

Audio verification Level 1 / above 2 only / all users

FTP client Alarm image transmission, periodic image transmission (when FTP periodic image transmission fails,

The image can be backed up in the sdxc/sdhc/sd memory card.)

Clients supported at the same time Up to 14 (depending on the network)

SDXC / SDHC / SD memory card

(optional)

*Panasonic manufacturing (SD speed class 4 or higher)

*In the case of SD speed class 10, use SD memory card conforming to uhs-1 (superelevation-1) H. 264 record: manual record / alarm record (front / rear) schedule rec / backup in case of network failure

JPEG record: manual record / alarm record (front / rear) / backup in case of network failure, compatible SD (SDHC / SDXC) card: Panasonic 2GB, 4gb*, 8gb*, 16gb*, 32gb*, 64gb* * SDHC card * *sdxc card (except miniSD card and microSD card)

call the police Alarm source Three terminal input, VMD, command alarm, audio detection alarm

schedule Alarm / VMD / access permission / H.264 record / scenario file

I / O Monitor output (for debugging) VBS：1.0 V[P-P] / 75 Ω，ø 3.5mm video output small socket

Microphone / line in Mic in and line in are optional. ø 0.35mm mono audio interface (mono input)

(microphone applicable: power type) supply voltage: 2.5V ± 0.5V, input impedance: About 2K Ω( Unstable)

Audio output ø Output impedance of 3.5mm stereo audio interface (dual channel output): about 600 Ω( Unstable)

External I / O port Alarm input 1 / day / night conversion input, alarm input 2 / alarm output, alarm input 3 / auxiliary output

RS485 support

General specifications security UL(UL60950-1)，C-UL(CAN/CSA C22.2 No.60950-1)，CE，IEC60950-1

EMS FCC(Part15 ClassA)，ICES003 ClassA，EN55022 ClassB，EN55024

Power / power consumption When the infrared LED is on

Power supply: AC 24V / about 7.9w

Poe device: DC 48V / about 170ma / 8.2w (Class 0 equipment)

Working environment temperature - ten ˚ C~+50 ˚ C

Working environment humidity 20% - 90% (no condensation)

size ø 129.5mmx101.5mm (H) ball cover radius 40mm

Weight (approximately) 430g

Finish Main engine: ABS resin sail white / hemispherical cover acrylic resin

*1 conversion value.

*2. Super wide dynamic function will be automatically started in 60fps mode.

*4-stream transmission can be set separately in the same compression method.
